Home  >> Omnidirectional > AM-O97A44-NT



Omnidirectional Unidirectional Noise Cancelling Entire microphpone



Condenser Microphone Microphone

1 Electret Type Foil type
2 Sensitivity -44±3dB (0dB=1V/Pa,1KHz)Band form 300 to 3K Hz
3 Standard Operation Voltage 2.0V
4 Output Impedance (Max) 2.2KΩ
5 Directivity Omnidirectional
6 Frequency Range 70 - 20K Hz
7 Max. Operation Voltage 10V
8 Current Consumption Max.0.5mA
9 Sensitivity Reduction Within -3dB 0dB=1V/Pa,1KHz Vs=2.0 to 1.5V
10 S/N Ratio > 58dB
11 Operating Temperature -20~+60℃
12 Storage Temperature -30~+70℃















 Data Sheet
